Nutanix Security Hardening AOS 7.5, Part 2: Cluster Lockdown & Encryption

Part 2 of our AOS 7.5 security series covers locking down cluster access and encrypting data at rest and in transit.

If you haven't read it yet, start with Part 1: CVM, PCVM & AHV Hardening.

Cluster Lockdown Configuration#

Cluster lockdown disables password-based SSH authentication and requires public key authentication.

Enable Cluster Lockdown During Cluster Creation#

Create a cluster with lockdown mode and custom password:

cluster --password_lockdown_mode=true \
  --cluster_create_password_enforcement=true \
  --cluster_create_security_opts=true \
  --encrypted_password="encrypted_string" \
  --external_access_keys="public_key" create

Create a cluster with full lockdown (no password or SSH key access):

cluster --lockdown_mode=true \
  --cluster_create_password_enforcement=true \
  --cluster_create_security_opts=true create

Configure Cluster Lockdown via Prism Element#

1. Log in to Prism Element as administrator
2. Click the gear icon → Cluster Lockdown
3. Deselect Enable Remote Login with Password
4. Click + New user SSH Key
5. Enter a name and paste the public key value
6. Click Save

Data-at-Rest Encryption#

AOS 7.5 supports software-based encryption using AES-256 with multiple key management options.

Configure External KMS with Prism Central#

First, register the external KMS:

mantle_cli kms kmip create \
  --name my_external_kms \
  --ca_cert_path /path/to/ca.crt \
  --client_cert_path /path/to/client.crt \
  --private_key_path /path/to/client.key \
  --ip_port_vec "10.0.1.50:5696,10.0.1.51:5696"

List configured KMS entries:

mantle_cli kms kmip list

Associate the external KMS with a cluster:

ncli key-management-server change-key-manager-server-type \
  key-manager-server-type=ekm_pc \
  kms-uuids=<kms_uuid>

Update External KMS Configuration#

mantle_cli kms kmip update \
  --kms_uuid <kms_uuid> \
  --ca_cert_path /path/to/new-ca.crt \
  --client_cert_path /path/to/new-client.crt \
  --private_key_path /path/to/new-client.key \
  --ip_port_vec "10.0.1.52:5696"

Verify the update:

mantle_cli kms kmip get --kms_uuid <kms_uuid>

Data-in-Transit Encryption#

AOS 7.5 supports encrypting data as it moves between CVMs in the cluster.

Enable data-in-transit encryption via Prism Central:

1. Navigate to Admin Center → Security
2. Select the cluster
3. Enable Data-in-Transit Encryption

IP Set Based Firewall#

AOS 7.5 enables IP set-based firewall by default. This implements strict firewall rules for intra-cluster communication, allowing only trusted CVM and hypervisor IP addresses as sources for RPC and API requests.

This feature is enabled automatically in AOS 6.8 and later.

Summary#

With cluster lockdown and encryption configured, your Nutanix infrastructure now has strong access controls and data protection. In Part 3, we cover IAM configuration and troubleshooting.
